15
REPEATER AND DUPLEX OPERATIONS
15-6
■ Auto repeater function
When the operating frequency falls within the repeater
output frequency range, the Auto Repeater function
can automatically sets the repeater settings (duplex
ON/OFF, duplex direction, tone encoder ON/OFF).
The Auto repeater function uses the preset repeater
tone frequency and frequency offset.
See page 16-16 for details of the setting.
Push [MENU] .
Push D-pad() to
select, then push
D-pad(Ent).
Push D-pad() to
select, then push
D-pad(Ent).
D Frequency range and offset direction
• USA version
FREQUENCY RANGE SHIFT DIRECTION
145.200~145.495 MHz “DUP–” is set
146.610~146.995 MHz “DUP–” is set
147.000~147.395 MHz “DUP+” is set
442.000~444.995 MHz “DUP+” is set
447.000~449.995 MHz “DUP–” is set
• Korean version
FREQUENCY RANGE SHIFT DIRECTION
439.000~440.000 MHz “DUP–” is set
D Auto repeater setting
q Push [MENU] to enter the MENU screen.
w Push D-pad() to select the root item (“Function”),
and then push D-pad(Ent).
e Push D-pad() to select “Auto Repeater,” and then
push D-pad(Ent).
r Rotate [DIAL] to select the Auto repeater setting.
USA version:
• OFF : The Auto repeater function is OFF.
• ON (DUP) : Turns ON only the duplex operation.
(Default)
• ON (DUP, TONE) : Turns ON the duplex operation and
tone encoder
Korean version:
• OFF : The Auto repeater function is OFF.
• ON : Turns ON the duplex operation and tone encoder.
(Default)
t Push [MENU] to save, and exit the MENU screen.
[DIAL]
NOTE: When turned ON, the Auto repeater function
uses the preset repeater tone frequency and frequency
offset. See page 16-16 for details of the setting.
NOTE:
For the USA and Korean versions:
When turned ON, the Auto repeater function has pri-
ority over the manual duplex setting. If the transmit
frequency changes after setting, the Auto repeater
function may have changed the duplex setting.
