15
REPEATER AND DUPLEX OPERATIONS
15-5
■ Duplex operation (Continued)
D Setting the duplex direction
q Push [V/MHz] to select the VFO mode.
w Rotate [DIAL] to set the operating frequency.
e Push [QUICK] .
r Push D-pad() to select “DUP,” and then push D-
pad(Ent).
t Push D-pad() to select “DUP–” (negative offset) or
“DUP+” (positive offset), and then push D-pad(Ent)
to save, and exit the Quick Menu screen.
• OFF : For simplex operation (the receive and transmit
frequencies are the same).
• DUP– : The transmit frequency shifts down from the re-
ceive frequency by the offset amount.
• DUP+ : The transmit frequency shifts up from the receive
frequency by the offset amount.
[DIAL]
■ Off band indication
If the transmit frequency is out of the amateur band, the
off band indication, “OFF,” appears on the display when
[PTT] is pushed. Check the frequency offset (p. 15-4) or
duplex direction (see above) in this case.
Push D-pad() to
select, then push
D-pad(Ent).
Push D-pad() to
select, then push
D-pad(Ent).
D Duplex operation
q Push [MODE] several times to select the FM
mode.
w Hold down [SQL] to listen on the repeater input fre-
quency.
• The transmit frequency (repeater input frequency) ap-
pears on the function display.
e Communicate in the normal way.
While monitoring
[SQL]
Blinks
NOTE: When the Auto repeater is ON, and the oper-
ating frequency is set out of the repeater output fre-
quency range, the duplex is automatically cancelled.
To Next Page
