OTHER FUNCTIONS
17-23
■ CI-V information (Continued)
D Command table
Cmd.
Sub
cmd.
Data
Description
00 see p. 17-24 Send operating frequency for transceive
01 see p. 17-24 Send operating mode for transceive
03 see p. 17-24 Read operating frequency
04 see p. 17-24 Read operating mode
05 see p. 17-24 Send operating frequency
06 see p. 17-24 Send operating mode
07 Select the VFO mode
D0 Select A band
Dualwatch: Set the Main band as the A band
Single watch: Select the A band
D1 Select B band
Dualwatch: Set the Main band as the B band
Single watch: Select the B band
0C see p. 17-24 Read frequency offset*
1
0D see p. 17-24
Send frequency offset
0F Read duplex setting
(10= simplex, 11= DUP–, 12= DUP+)
10
Set simplex operation
11
Set DUP– operation
12
Set DUP+ operation
11 00 Send/read attenuator OFF (AIR band)
30 Send/read 30 dB attenuator (AIR band)
14 01 see p. 17-24 Send/read audio output level
03 see p. 17-24 Send/read squelch level
0A see p. 17-24 Send/read RF power setting
0B see p. 17-24 Send/read external microphone gain.
16 see p. 17-24 Send/read VOX gain.
15 01 00 Read noise/S-meter squelch status (squelch
close)
01 Read noise/S-meter squelch status (squelch
open)
02 0000 to
0255
Read S-meter level (0000= S0, 0170= S9)
05 00 Read tone squelch and RF squelch status
(squelch close)
01 Read tone squelch and RF squelch status
(squelch open)
11
0000 to
0255
Read RF power meter
( 0005= S-LOW, 0026= LOW1, 0051= LOW2,
0128= MID, 0255= HIGH)
16 42 00 Send/read Repeater tone OFF
01
Send/read Repeater tone ON
43
00
Send/read Tone squelch OFF
01
Send/read Tone squelch ON
02
Send/read Reversed Tone squelch ON
46
00
Send/read VOX function OFF
01
Send/read VOX function ON
4B
00
Send/read DTCS OFF
01
Send/read DTCS ON
02
Send/read Reversed DTCS ON
59
00
Send/read Sub band OFF
01
Send/read Sub band ON
5B
00
Send/read DSQL/CSQL OFF (DV mode only)
01
Send/read DSQL ON (DV mode only)
02
Send/read CSQL ON (DV mode only)
5C 00, 01, 02 Send/read GPS TX mode
(00= OFF, 01= D-PRS, 02= NMEA)
5D 00 to 09 Send Tone setting
( 00= OFF, 01= TONE, 02= TSQL, 03=DTCS,
04=TSQL-R, 05=DTCS-R, 06=DTCS(T),
07=TONE(T)/DTCS(R), 08=DTCS(T)/TSQL(R)
,
09=TONE(T)/TSQL(R))
18 00 Turning the transceiver power OFF
01 Turning the transceiver power ON*
2
19 00 Read transceiver ID.
Cmd.
Sub
cmd.
Data
Description
1B 00
see p. 17-24
Send/read Repeater tone frequency
01
see p. 17-24
Send/read Tone squelch frequency
02
see p. 17-25
Send/read DTCS code and polarity
07
see p. 17-25
Send/read CSQL code (DV mode)
1C 00 00
Send/read Transceiver’s status (RX)
01
Send/read Transceiver’s status (TX)
1F 00
see p. 17-25 Send/read DV MY call sign
01
see p. 17-25 Send/read DV TX call signs
02
see p. 17-25
Send/read DV TX message
20 00 00
00*
3
Send/read Auto DV RX Call signs output OFF
01*
3
Send/read Auto DV RX Call signs output ON
01
see p. 17-26
Output DV RX Call signs
02
see p. 17-26
Read DV RX Call signs
01 00
00*
3
Send/read Auto DV RX message output OFF
01*
3
Send/read Auto DV RX message output ON
01
see p. 17-26
Output DV RX message
02
see p. 17-26
Read DV RX message
02 00
00*
3
Send/read Auto DV RX status output OFF
01*
3
Send/read Auto DV RX status output ON
01
see p. 17-25
Output DV RX status
02
see p. 17-25
Read DV RX status
03 00 00 Send/read Auto DV RX GPS/D-PRS data
output OFF
01 Send/read Auto DV RX GPS/D-PRS data
output ON
01 see p. 17-26
~ p. 17-28
Output DV RX GPS/D-PRS data for transceive
02 see p. 17-26
~ p. 17-28
Read DV RX GPS/D-PRS data for transceive
04 00 00 Send/read Auto DV RX GPS/D-PRS mes-
sage output OFF
01 Send/read Auto DV RX GPS/D-PRS mes-
sage output ON
01 see p. 17-28
Output DV RX GPS/D-PRS message for transceive
02 see p. 17-28
Read DV RX GPS/D-PRS message for transceive
22 00 see p. 17-28 Send/read DV TX data (Up to 30 bytes)
01 00 00 Send/read Auto DV RX data output OFF
01 Send/read Auto DV RX data output ON
01 see p. 17-28 Send/read DV RX data (Up to 30 byte)
02 00, 01
Send/read DV data TX setting (00=PTT, 01=Auto)
03 00, 01
Send/read DV fast data setting (00=OFF, 01=ON)
04 00, 01
Send/read GPS Data Speed setting
(00=Slow, 01=Fast)
05 00~10
Send/read TX Delay (PTT) setting
(00=OFF, 01=1 sec.
~ 10=10 sec.
)
*
1
: Less than 100 Hz is omitted.
*
2
: When sending the power ON command (18 01), the command
“FE” must be sent before the basic format.
• 19200bps: 50 • 9600bps: 26 • 4800bps: 14
• 1200bps: 5 • 300bps: 3
qwert
u
F
F E
68EFEE 1081
F
Example: When operating with 4800 bps
q Preamble code (fixed) w Transceiver’s default address
e Controller’s default address r Command number
t Sub command number u End of message code (fixed)
*
3
: Output setting is automatically turned OFF after turning the power
OFF, then ON.
