Icom ID-51A User Manual

17
OTHER FUNCTIONS
17-20
• Connections
• Connections
■ Cloning function (Continued)
D Cloning from a PC using a microSD card
The cloning can be performed from a PC using a mi-
croSD card.
Set a desired memory channels, MENU item settings
and Repeater List by the CS-51PLUS2 cloning soft-
ware (contained in the CD), and save them in an “icf”
file format. Copy the “icf” file into the “Setting” folder in
the “ID-51” folder of the microSD card.
• microSD card configuration
Attach the microSD card that includes the “icf” file, then
load it to complete the cloning.
D Cloning from a PC using an optional data cable
Cloning can be performed using the CS-51PLUS2
(contained in the CD) and the optional data communi-
cation cable.
See the CS-51PLUS2 instruction manual contained in
the CD and the data communication cable’s instruction
manual (downloaded from the Icom WEB site; http://www.
icom.co.jp/world/).
NOTE: When using the optional data communica-
tion cable
• Before cloning, select “PTT” option in DV Data TX
item. If “Auto” is selected, the transceiver may trans-
mit with the cloning data.
(DV Set > DV Data TX)
• Before cloning, select the Clone mode in the MENU
screen.
(Other > Clone Mode)
Click
Click
Card reader
Or
CS-51PLUS2
CS-51PLUS2
To the [DATA] jack
OPC-2218LU (Option)
OPC-2350LU (Option)
To a [USB] port
PC
Tr
ansceiver
"Clone Mode"
CS-51PLUS2
Copy the
“icf” file.
Click
ID-51
Gps
Reply
Setting
Voice yyyymmdd
yyyymmdd
QsoLog
RxLog
VoiceRec
VoiceTx
Csv
GpsMemory
RptList
YourMemory
yyyymmdd
yyyymmdd
Previous view

Icom ID-51A Specifications

General

Frequency Range	144-148 MHz, 430-450 MHz
Antenna Connector	SMA
GPS Receiver	Yes
Waterproof	IPX7
Modes	FM, DV
Weight	255 g
Memory Channels	1304 channels
Output Power	5W (High), 2.5W (Middle), 0.5W (Low)
