Icom ID-51A User Manual

10
GPS OPERATION
10-9
■ Checking GPS Position (Continued)
D TX format: D-PRS Weather
The following items are displayed when the caller’s TX
format is D-PRS Weather.
Compass
Displays the caller’s direction from
your position
Symbol
Displays the caller station’s D-PRS
symbol
Latitude Displays the caller’s latitude
Longitude Displays the caller’s longitude
GL
Displays the grid locator based on the
caller’s latitude and longitude.
DST
Displays the caller’s distance from
your position
Call sign
Displays the caller’s call sign (with
SSID)
Temperature
Displays the temperature at the call-
er’s area
Humidity
Displays the humidity at the caller’s
area
RAIN
Displays the rainfall at the caller’s
area
WIND DIR
Displays the wind direction at the
caller’s area
WIND SPD
Displays the wind speed at the call-
er’s area
BARO
Displays the barometric pressure at
the caller’s area
GPS Time Stamp
Displays the time that the caller
acquired the weather data.
D TX mode: NMEA
The following items are displayed when the caller’s TX
mode is NMEA.
Compass*
Displays the caller’s direction from
your position.
Latitude Displays the caller’s latitude
Longitude Displays the caller’s longitude
GL
Displays the grid locator based on the
caller’s latitude and longitude.
ALT Displays the caller’s altitude
DST
Displays the caller’s distance from
your position
Call sign Displays the caller’s call sign
COURSE
Displays the caller’s direction over
ground
SPEED Displays the caller’s speed
GPS Time Stamp
Displays the time that the caller
acquired the position data.
