Icom ID-51A User Manual

9
D-STAR OPERATION <ADVANCED>
9-47
You can check the Repeater List default values using
the supplied CS-51PLUS2 cloning software.
The ICF (Icom Cloning Format) file, including the de-
fault Repeater List, can also be downloaded from the
Icom website.
http://www.icom.co.jp/world/support/download/firm/
index.html
If you open the downloaded ICF file with the CS-
51PLUS2, the Repeater List default values are dis-
played on the screen.
To reset the Repeater List to the default, write the ICF
file to the transceiver using the CS-51PLUS2*
1
, or copy
the ICF file to the microSD card*
2
, and then write to the
transceiver.
*
1
See the CS-51PLUS2 instruction manual when us-
ing the CS-51PLUS2.
*
2
See page 2-10 when using the microSD card.
D Opening the default Repeater List
q Start the CS-51PLUS2.
• See the CS-51PLUS2 instruction manual for how to in-
stall the software.
w Click [Open] to open the ICF file.
e Click the [Repeater List] folder to show the default
Repeater List.
■ About the Repeater List default values
When the ICF file is opened on the CS-51PLUS2.
Select
Double-
click
Click
You can see
the default
values of the
Repeater List
on the CS-
51PLUS2.
Previous view

Icom ID-51A Specifications

General

Frequency Range	144-148 MHz, 430-450 MHz
Antenna Connector	SMA
GPS Receiver	Yes
Waterproof	IPX7
Modes	FM, DV
Weight	255 g
Memory Channels	1304 channels
Output Power	5W (High), 2.5W (Middle), 0.5W (Low)
