10
GPS OPERATION
10-32
■ Transmitting NMEA data (Continued)
D Entering a GPS message
Enter a GPS message of up to 20 characters to be
transmitted with the NMEA (DV-G) data.
q Push [MENU]
.
w Push D-pad() to select the root item (“GPS”), and
then push D-pad(Ent) to go to the next screen.
( MENU > GPS > GPS TX Mode > NMEA(DV-G) >
GPS Message)
e Refer to the menu sequence shown directly above,
and push D-pad() to select, and then D-pad(Ent)
to enter, one or more times until the last screen is
displayed.
r Push [QUICK] .
t
Push D-pad() to select “Edit,” and then push D-
pad(Ent).
y The message editing screen appears.
u Rotate [DIAL] to select the first character.
(Example: O)
• Selectable input characters are upper case letters, lower
case letters, numbers or symbols.
• The selected character blinks.
• Push D-pad() to move the cursor forward or backward.
• While selecting a character, push [QUICK]
to change
the character to an upper case or lower case letter.
• While selecting a digit, push [QUICK]
to open the
input mode selection window.
• A space can be entered in any input mode.
• Rotate [DIAL] counterclockwise to enter a space.
• Push [CLR]
to delete the selected character, or hold
down [CLR]
to continuously delete the characters,
first to the right, and then to the left of the cursor.
• See page 2-8 for entry details.
i Push D-pad() to move the cursor to the second
digit.
o Repeat steps u and i to enter a group name of up
to 20 characters, including spaces.
!0 After entering, push D-pad(Ent).
!1 Push [MENU] to exit the Menu screen.
GPS MESSAGE
screen
Input mode
selection
window
Example: Adding “OSAKA suzuki”
Insert a space
after entering
“OSAKA.”
To Next Page
