■ CI-V information
D Command table (Continued)
Cmd. Sub
cmd.
Data
Description
23 00 see p. 17-28 Read the position
01 00 Send/read the internal GPS OFF
01 Send/read the internal GPS ON
03 Send/read the manual input
02 see p. 17-28 Send/read manually input position
24 00 00 00 Send/read TX output power setting OFF
01 Send/read TX output power setting ON
01 00 TX output power setting OFF for transceive
01 TX output power setting ON for transceive
• Receive frequency setting
Command: 00, 03, 05
* 10 Hz digit is fixed to “5” when 100 Hz digit is either “2” or “7,”
and fixed to “0” when 100 Hz digit is other than “2” and “7.”
• Duplex Frequency offset setting
Command: 0C, 0D
• Audio output level setting
Command: 1401
• Operating mode
Command:01, 04, 06
Operating mode
q Mode w Filter setting
FM 05 01
FM-N 05 02
DV 17 01
q
X
XX
X
w
VOL0 VOL1 VOL2 VOL3 VOL4
0000 ~ 0005 0006 ~ 0012 0013 ~ 0018 0019 ~ 0025 0026 ~ 0031
VOL5 VOL6 VOL7 VOL8 VOL9
0032 ~ 0037 0038 ~ 0044 0045 ~ 0050 0051 ~ 0057 0058 ~ 0063
VOL10 VOL11 VOL12 VOL13 VOL14
0064 ~ 0069 0070 ~ 0076 0077 ~ 0082 0083 ~ 0089 0090 ~ 0095
VOL15 VOL16 VOL17 VOL18 VOL19
0096 ~ 0101 0102 ~ 0108 0109 ~ 0114 0115 ~ 0121 0122 ~ 0127
VOL20 VOL21 VOL22 VOL23 VOL24
0128 ~ 0133 0134 ~ 0140 0141 ~ 0146 0147 ~ 0153 0154 ~ 0159
VOL25 VOL26 VOL27 VOL28 VOL29
0160 ~ 0165 0166 ~ 0172 0173 ~ 0178 0179 ~ 0185 0186 ~ 0191
VOL30 VOL31 VOL32 VOL33 VOL34
0192 ~ 0197 0198 ~ 0204 0205 ~ 0210 0211 ~ 0217 0218 ~ 0223
VOL35 VOL36 VOL37 VOL38 VOL39
0224 ~ 0229 0230 ~ 0236 0237 ~ 0242 0243 ~ 0249 0250 ~ 0255
qew
XXXXXX
100 Hz digit
100 kHz digit
10 kHz digit
10 MHz digit
1 kHz digit
1 MHz digit
q
0XXXX
we
X
rt
XX X0
10H zdigit：0, 5 (according to the 100 Hz digit)
1 Hz digit：0 (Fixed) 1 kHz digit：0~9 100 Hz digit：0,2 , 5, 7 100 kHz digit：0~9 10 kHz digit：0~9 10 MHz digit：0~9 1 MHz digit：0~9 1000 MHz digit：0 (Fixed) 100 MHz digit：0~4
00XXXX
q※ we
固定:0 固定:0 100Hz桁 10Hz桁 1Hz桁 0.1Hz桁
XXX0
qw
1kHz桁:0〜3 100Hz桁：0〜9 10Hz桁：0〜9 1Hz桁:0 (固定)
XX0 XXX
q* we
0 (fixed) First digit: 0~7 Second digit: 0~7 Third digit: 0~7
Receive polarity: 0: Normal
1: Reverse
Transmit polarity: 0: Normal
1: Reverse
• Squelch level setting
Command: 1403
• External microphone gain setting
Command: 140B
• RF power level setting
Command: 140A
OPEN AUTO LEVEL1 LEVEL2 LEVEL3
0000 ~ 0022 0023 ~ 0046 0047 ~ 0069 0070 ~ 0092 0093 ~ 0115
LEVEL4 LEVEL5 LEVEL6 LEVEL7 LEVEL8
0116 ~ 0139 0140 ~ 0162 0163 ~ 0185 0186 ~ 0208 0209 ~ 0232
LEVEL9
0233 ~ 0255
1 2 3 4
0000 ~ 0063 0064 ~ 0127 0128 ~ 0191 0192 ~ 0255
S-LOW LOW1 LOW2 MID HIGH
0000 ~ 0050 0051 ~ 0101 0102 ~ 0153 0154 ~ 0204 0205 ~ 0255
• VOX gain setting
Command: 1416
OFF 1 2 3 4
0000 ~ 0022 0023 ~ 0046 0047 ~ 0069 0070 ~ 0092 0093 ~ 0115
5 6 7 8 9
0116 ~ 0139 0140 ~ 0162 0163 ~ 0185 0186 ~ 0208 0209 ~ 0232
10
0233 ~ 0255
• Repeater tone/tone squelch frequency setting
Command: 1B 00, 1B 01
q* ew
00XXXX
Fixed: 0 Fixed: 0 100 Hz digit 10 Hz digit 1 Hz digit 0.1 Hz digit
*Not necessary when setting a frequency.
See page 16-16 for tone frequency list.
