Icom ID-51A User Manual

16
MENU SCREEN
16-60
■ DV Set items
RX Bass (Default: Normal)
DV Set > Tone Control > RX Bass
Set the DV mode received audio bass filter level to Cut, Normal or Boost.
• Cut: Cuts the bass tone
• Normal: Normal tone level
• Boost: Boosts the bass tone
RX Treble (Default: Normal)
DV Set > Tone Control > RX Treble
Set the DV mode received audio treble filter level to Cut, Normal or Boost.
• Cut: Cuts the treble tone
• Normal: Normal tone level
• Boost: Boosts the treble tone
RX Bass Boost (Default: OFF)
DV Set > Tone Control > RX Bass Boost
Turn the DV mode received audio Bass Boost function ON or OFF.
This function is separate from the “Boost” setting of the RX Bass.
• OFF: Turns the function OFF.
• ON: This function boosts the received audio bass to output it from a
speaker, even if the speaker is small.
TX Bass (Default: Normal)
DV Set > Tone Control > TX Bass
Set the DV mode transmit audio bass filter level to Cut, Normal or Boost.
• Cut: Cuts the bass tone
• Normal: Normal tone level
• Boost: Boosts the bass tone
TX Treble (Default: Normal)
DV Set > Tone Control > TX Treble
Set the DV mode transmit audio treble filter level to Cut, Normal or Boost.
• Cut: Cuts the treble tone
• Normal: Normal tone level
• Boost: Boosts the treble tone
Previous view

Icom ID-51A Specifications

General

Frequency Range	144-148 MHz, 430-450 MHz
Antenna Connector	SMA
GPS Receiver	Yes
Waterproof	IPX7
Modes	FM, DV
Weight	255 g
Memory Channels	1304 channels
Output Power	5W (High), 2.5W (Middle), 0.5W (Low)
