Icom ID-51A User Manual

5
BASIC OPERATION
5-7
■ Selecting the tuning step
The following tuning steps are selectable. (kHz)
5.0 6.25 8.33* 10.0 12.5 15.0 20.0
25.0 30.0 50.0 100.0 125.0 200.0
*Appears only when the AIR band is selected.
D Tuning step selection
q Push [QUICK] to open the Quick Menu screen.
w Push D-pad() to select “TS,” and then push D-
pad(Ent).
D-pad
()
(Ent)
e Push D-pad() to select the desired tuning step.
r Push D-pad(Ent) to save the setting and exit the
Quick Menu screen.
When 10 kHz tuning steps
is selected, the frequency
changes in the 10 kHz steps.
Previous view

Icom ID-51A Specifications

General

Frequency Range	144-148 MHz, 430-450 MHz
Antenna Connector	SMA
GPS Receiver	Yes
Waterproof	IPX7
Modes	FM, DV
Weight	255 g
Memory Channels	1304 channels
Output Power	5W (High), 2.5W (Middle), 0.5W (Low)
