16
MENU SCREEN
16-36
GPS Position (Continued)
3. When the caller’s TX format is D-PRS Position (Base station)
Compass* Displays the caller’s direction from your position
Symbol Displays the caller’s D-PRS symbol
Latitude Displays the caller’s latitude
Longitude Displays the caller’s longitude
GL
Displays the grid locator based on the caller’s latitude and
longitude.
ALT Displays the caller’s altitude
DST Displays the caller’s distance from your position
Call sign Displays the caller’s call sign (with SSID)
POWER Displays the caller’s TX power level
HEIGHT Displays the height of caller’s antenna
GAIN Displays the gain of caller’s antenna
DIRECT Displays the direction of caller’s antenna was pointing
GPS Time Stamp Displays the time that the caller acquired the position data.
4. When the caller’s TX format is
D-PRS Object/Item
Compass* Displays the Object/Item station’s direction from your position
Symbol Displays the Object/Item station’s D-PRS symbol
Latitude Displays the Object/Item station’s latitude
Longitude Displays the Object/Item station’s longitude
GL
Displays the grid locator based on the Object/Item station’s
latitude and longitude.
ALT Displays the Object/Item station’s altitude
DST Displays the Object/Item station’s distance from your position
Object/Item name Displays the Object/Item station’s name
Call sign Displays the caller’s call sign (with SSID)
COURSE Displays the Object/Item station’s direction over ground
SPEED Displays the Object/Item station’s speed
POWER Displays the Object/Item station’s TX power level
HEIGHT Displays the height of Object/Item station’s antenna
GAIN Displays the gain of Object/Item station’s antenna
DIRECT
Displays the direction that the Object/Item station’s antenna was
pointing
GPS Time Stamp Displays the time that the caller sent the Object station’s data.
When the object or item station is disabled, “KILLED” appears.
*These items can be selected in the Quick Menu screen.
■ GPS items (Continued)
