16
MENU SCREEN
16-50
GPS items (Continued)
GPS Message
GPS > GPS TX Mode > NMEA (DV-G) > GPS Message
Enter a GPS message of up to 20 alphanumeric characters. (p. 10-32)
GPS Message edit screen
This GPS Message item will be hidden when “D-PRS (DV-A)” or “OFF” is
selected in “GPS TX Mode.
NOTE: When no message transmission is desired, delete the entered mes-
sage in the QUICK MENU screen.
GPS Auto TX (Default: OFF)
GPS > GPS Auto TX
Select an option for the GPS automatic transmission function.
This function automatically transmits the current position data received from
a GPS receiver, as well as any entered GPS message, at the selected inter-
val.
OFF: Turns the function OFF. However, you can transmit the po-
sition data manually by pushing [PTT].
• 5 sec to 30 min: Transmits the current position data at the selected interval
(5*, 10, or 30 seconds, or 1, 3, 5, 10, or 30 minutes).
* When four GPS sentences are selected at the same time
in GPS Sentence Mode, “5sec” cannot be selected.
NOTE: When “Manual” is selected in GPS Select, the current position data
will not be automatically transmitted.
