16
MENU SCREEN
16-55
■ RX History items (Continued)
2. When the caller’s TX format is D-PRS Position
(Mobile station)
Compass*
Displays the caller’s direction from your
position
Symbol Displays the caller’s D-PRS symbol
Latitude Displays the caller’s latitude
Longitude Displays the caller’s longitude
GL
Displays the grid locator based on the
caller’s latitude and longitude.
ALT Displays the caller’s altitude
DIST*
Displays the caller’s distance from your
position
Call sign Displays the caller’s call sign (with SSID)
COURSE
Displays the caller’s direction over ground
SPEED Displays the caller’s speed
GPS Time Stamp
Displays the time that the caller acquired
the position data.
GPS MESSAGE
Displays the GPS message included in
the position data of the received call.
3. When the caller’s TX format is D-PRS Position
(Base station)
Compass*
Displays the caller’s direction from your
position
Symbol Displays the caller’s D-PRS symbol
Latitude Displays the caller’s latitude
Longitude Displays the caller’s longitude
GL
Displays the grid locator based on the
caller’s latitude and longitude.
ALT Displays the caller’s altitude
DIST*
Displays the caller’s distance from your
position
Call sign Displays the caller’s call sign (with SSID)
POWER Displays the caller’s TX power level
HEIGHT Displays the height of caller’s antenna
GAIN
Displays the gain of caller’s antenna
DIRECT
Displays the direction that the caller’s an-
tenna was pointing
GPS Time Stamp
Displays the time that the caller acquired
the position data.
GPS MESSAGE
Shows the GPS message included in the
position data of the received call.
4. When the caller’s TX format is
D-PRS Object/Item
Compass*
Displays the Object/Item station’s
direction from your position
Symbol
Displays the Object/Item station’s D-PRS
symbol
Latitude
Displays the Object/Item station’s latitude
Longitude
Displays the Object/Item station’s longitude
GL
Displays the grid locator based on the
Object/Item station’s latitude and longitude.
ALT
Displays the Object/Item station’s altitude
DST*
Displays the Object/Item station’s distance
from your position
Object/Item name Displays the Object/Item station’s name
Call sign Displays the caller’s call sign (with SSID)
COURSE
Displays the Object/Item station’s direction
over ground
SPEED Displays the Object/Item station’s speed
POWER
Displays the Object/Item station’s TX power
level
HEIGHT
Displays the height of Object/Item station’s
antenna
GAIN
Displays the gain of Object/Item station’s
antenna
DIRECT
Displays the direction that the Object/
Item station’s antenna was pointing
GPS Time Stamp
Displays the time that the caller sent the
Object station’s data.
GPS MESSAGE
Shows the GPS message included in the
position data of the received call.
When the object or item station is disabled, “KILLED”
appears.
5. When the caller’s TX format is D-PRS
Weather
Compass*
Displays the caller’s direction from your
position
Symbol Displays the caller’s D-PRS symbol
Latitude Displays the caller’s latitude
Longitude Displays the caller’s longitude
GL
Displays the grid locator based on the
caller’s latitude and longitude
DST
Displays the caller’s distance from your
position
Call sign Displays the caller’s call sign (with SSID)
Temperature
Displays the temperature at the caller
station’s area
Humidity
Displays the humidity at the caller sta-
tion’s area
RAIN
Displays the rainfall at the caller station’s
area
WIND DIR
Displays the wind direction at the caller
station’s area
WIND SPD
Displays the wind speed at the caller sta-
tion’s area
BARO
Displays the barometric pressure at the
caller station’s area
GPS Time Stamp
Displays the time that the caller acquired
the weather data.
GPS MESSAGE
Shows the GPS message included in the
position data of the received call.
*
If you have no position data, these items are not displayed.
To Next Page
