18
OPTIONS
18-3
Icom is not responsible for the destruction, damage
to, or performance of any Icom or non-Icom equip-
ment, if the malfunction is because of:
• Force majeure, including, but not limited to, fires,
earthquakes, storms, floods, lightning, other natu-
ral disasters, disturbances, riots, war, or radioactive
contamination.
• The use of Icom transceivers with any equipment
that is not manufactured or approved by Icom.
D BATTERY PACKS/CASE
• BP-271 li-ion battery pack
7.4 V
1150 mAh (minimum)/1200 mAh (typical)
Battery life: Approximately 4.5 hours* (FM/DV)
• BP-272 li-ion battery pack
7.4 V
1880 mAh (minimum)/2000 mAh (typical)
Battery life: Approximately 8 hours* (FM)
Approximately 7 hours* (DV)
• BP-273 battery case
Battery case for three LR6 (AA) alkaline batteries.
*At High power, TX : RX: Standby = 1:1:8
D CHARGERS
• BC-167SA/SD/SV battery charger
To regular charge the BP-271 or BP-272 Lithium ion
battery pack.
Same as the supplied one. (Not supplied with some
transceiver versions.)
D SOFTWARE/CABLES
• CS-51PLUS2 cloning software
Free download software (contained in the CD)
Use this software to program settings such as mem-
ory channels and Menu mode contents quickly and
easily.
The OPC-2218LU, OPC-2350LU, or microSD card is
required.
• RS-MS1A remote control software
Free download software
Allows using the extended D-STAR functions to ex-
change image files or text messages, or display the
received D-PRS station data on a map application by
an Android™ device.
The OPC-2350LU is required.
• RS-MS3W remote control software
Free download software.
Allows using the DV Gateway function.
See “About the DV Gateway function” on the Icom
WEB site, http://www.icom.co.jp/world/ for details.
The OPC-2350LU is required.
• RS-MS3A remote control software
Free download software.
Allows using the DV Gateway function.
See “About the DV Gateway function” on the Icom
WEB site, http://www.icom.co.jp/world/ for details.
The OPC-2350LU is required.
• OPC-2218LU data cable
Allows DV data communication, or data cloning with
CS-51PLUS2 (contained in the CD).
• OPC-2350LU data cable
Allows DV data communication between the trans-
ceiver and an Android™ device, or data cloning with
CS-51PLUS2 (contained in the CD).
D OTHER OPTIONS
• HM-75A/HM-153/HM-166/HM-186 microphones or
SP-13 earphone +OPC-2144 plug adapter cable
HM-75A: Remote control Speaker microphone
HM-153: Earphone microphone
HM-166: Earphone microphone
HM-186: Speaker microphone
SP-13: Earphone
OPC-2144: Allows you to connect the HM-75A/HM-
153/HM-166/HM-186/SP-13 to the trans-
ceiver.
• HS-94/HS-95/HS-97 headset
+OPC-2006LS plug adapter cable
HS-94: Ear hook type
HS-95: Neck & arm type
HS-97: Throat microphone
OPC-2006LS
: Allows you to connect the HS-94/HS-95/
HS-97 to the transceiver. After connect-
ing, the VOX function can be used.
• LC-179 carrying case
Helps protect the transceiver from scratches, and so
on.
• SJ-1 silicone jacket
• AD-92SMA antenna connector adapter
Allows you to connect an antenna or antenna cable
that has a BNC connector.
• CT-17 ci-v level converter unit
For remote transceiver control using a personal com-
puter equipped with an RS-232C port. You can change
frequencies, operating mode, memory channels, and
so on, using your computer.
• FA-S270C antenna
Same as the supplied one.
• MB-127 belt clip
Same as the supplied one.
■ Option list (Continued)
