Intel Cyclone 10 GX User Manual

Parameter Gen1 PIPE Gen2 PIPE
Enable manual counter configuration Disable Disable
Enable ATX to fPLL cascade clock input
port
Disable Disable
Settings
Bandwidth Low, Medium, High Low, Medium, High
Feedback
Operation mode Direct Direct
Output frequency
Transceiver usage
PLL output frequency 1250MHz 2500MHz
PLL datarate 2500Mbps 5000Mbps
PLL integer reference clock frequency 100 MHz, 125 MHZ 100 MHz, 125 MHZ
Master Clock Generation Block (MCGB)
Include master clock generation block Disable for x1
Enable for x2, x4
Disable for x1
Enable for x2, x4
Clock division factor N/A for x1
1 for x2, x4
N/A for x1
1 for x2, x4
Enable x6/xN non-bonded high-speed
clock output port
N/A for x1
Disable for x2, x4
N/A for x1
Disable for x2, x4
Enable PCIe clock switch interface N/A for x1
Disable for x2, x4
N/A for x1
Enable for x2, x4
Number of auxiliary MCGB clock input
ports
N/A for x1
0 for x2, x4
N/A for x1
0 for x2, x4
MCGB input clock frequency 1250MHz 2500MHz
MCGB output data rate 2500Mbps 5000Mbps
Bonding
Enable bonding clock output ports N/A for x1 design
Enable for x2, x4
N/A for x1 design
Enable for x2, x4
Enable feedback compensation bonding N/A for x1 design
Disable for x2, x4
N/A for x1 design
Disable for x2, x4
PMA interface width N/A for x1 design
10 for x2, x4
N/A for x1 design
10 for x2, x4
Dynamic Reconfiguration
Enable dynamic reconfiguration Disable Disable
Enable Altera Debug Master Endpoint Disable Disable
Separate avmm_busy from
reconfig_waitrequest
N/A N/A
Optional Reconfiguration Logic
Enable capability registers N/A N/A
Set user-defined IP identifier N/A N/A
Enable control and status registers N/A N/A
continued...
2. Implementing Protocols in Intel Cyclone 10 GX Transceivers
UG-20070 | 2018.09.24
Intel
®
Cyclone
®
10 GX Transceiver PHY User Guide
Send Feedback
136
