Intel Cyclone 10 GX User Manual

Table 131. Channel Width Options for Supported Serial Data Rates
Serial Data
Rate
(Mbps)
Channel Width (FPGA-PCS Fabric)
8/10 Bit Width 16/20 Bit Width
8-Bit 16-Bit 16-Bit 32-Bit
614.4
(25)
Yes Yes N/A N/A
1228.8 Yes Yes Yes Yes
2457.6 Yes Yes Yes Yes
3072 Yes Yes Yes Yes
4915.2 N/A N/A Yes Yes
6144 N/A N/A Yes Yes
2.8.1.1. TX PLL Selection for CPRI
Choose a transmitter PLL that fits your required data rate.
Table 132. TX PLL Supported Data Rates
ATX and fPLL support the clock bonding feature.
TX PLLs Supported Data Rate (Mbps)
ATX 614.4, 1228.8, 2457.6, 3072, 4915.2, 6144
fPLL 614.4, 1228.8, 2457.6, 3072, 4915.2, 6144
CMU 614.4, 1228.8, 2457.6, 3072, 4915.2, 6144
Note: • Channels that use the CMU PLL cannot be bonded. The CMU PLL that provides the
clock can only drive channels in the transceiver bank where it resides.
• Over-sampling is required to implement 614.4 Mbps.
2.8.1.2. Auto-Negotiation
When auto-negotiation is required, the channels initialize at the highest supported
frequency and switch to successively lower data rates if frame synchronization is not
achieved. If your design requires auto-negotiation, choose a base data rate that
minimizes the number of PLLs required to generate the clocks required for data
transmission.
By selecting an appropriate base data rate, you can change data rates by changing the
local clock generation block (CGB) divider. If a single base data rate is not possible,
you can use an additional PLL to generate the required data rates.
Table 133. Recommended Base Data Rates and Clock Generation Blocks for Available
Data Rates
Data Rate (Mbps) Base Data Rate (Mbps) Local CGB Divider
1228.8 4915.2 4
2457.6 4915.2 2
continued...
(25)
Over-sampling is required to implement 614.4Mbps
2. Implementing Protocols in Intel Cyclone 10 GX Transceivers
UG-20070 | 2018.09.24
Intel
®
Cyclone
®
10 GX Transceiver PHY User Guide
Send Feedback
150
