Table 63. Standard PCS FIFO
Name Direction Clock Domain Description
tx_std_pcfifo_full[<n
>-1:0]
Output Synchronous
to the clock
driving the
write side of
the FIFO
(tx_coreclki
n or
tx_clkout)
Indicates when the standard TX FIFO is full.
tx_std_pcfifo_empty[<
n>-1:0]
Output Synchronous
to the clock
driving the
write side of
the FIFO
(tx_coreclki
n or
tx_clkout)
Indicates when the standard TX FIFO is empty.
rx_std_pcfifo_full[<n
>-1:0]
Output Synchronous
to the clock
driving the
read side of
the FIFO
(rx_coreclki
n or
rx_clkout)
Indicates when the standard RX FIFO is full.
rx_std_pcfifo_empty[<
n>-1:0]
Output Synchronous
to the clock
driving the
read side of
the FIFO
(rx_coreclki
n or
rx_clkout)
Indicates when the standard RX FIFO is empty.
Table 64. Rate Match FIFO
Name Direction Clock Domain Description
rx_std_rmfifo_full[<n
>-1:0]
Output Asynchronous Rate match FIFO full flag. When asserted the rate match
FIFO is full. You must synchronize this signal. This port is
only used for GigE mode.
rx_std_rmfifo_empty[<
n>-1:0]
Output Asynchronous Rate match FIFO empty flag. When asserted, match FIFO is
empty. You must synchronize this signal. This port is only
used for GigE mode.
rx_rmfifostatus[<n>-1
:0]
Output Asynchronous Indicates FIFO status. The following encodings are defined:
• 2'b00: Normal operation
•
2'b01: Deletion, rx_std_rmfifo_full = 1
•
2'b10: Insertion, rx_std_rmfifo_empty = 1
•
2'b11: Full. rx_rmfifostatus is a part of
rx_parallel_data. rx_rmfifostatus corresponds
to rx_parallel_data[14:13].
2. Implementing Protocols in Intel Cyclone 10 GX Transceivers
UG-20070 | 2018.09.24
Intel
®
Cyclone
®
10 GX Transceiver PHY User Guide
Send Feedback
64
