Lexmark CX310 Service Manual

• “PRINTER SETUP” on page 205
• “EP SETUP” on page 208
• “TPS Setup: Right or Left” on page 208
• “TPS Setup: Cal Ref Adj” on page 209
• “TPS Setup: Reset Color Cal” on page 209
• “Reports: Menu Settings Page” on page 209
• “EVENT LOG” on page 210
• “Scanner tests” on page 211
• “Exit Diagnostics” on page 216
The Diagnostics menu group contains the settings and operations used while manufacturing and servicing the printer.
Entering diagnostics mode
1 Turn off the printer.
2 Press and hold 3 and 6.
3 Turn on the printer.
4 Release the buttons when the installed memory and processor speed displays.
5 Select Exit Diags to exit Diagnostics mode and return to the printer home screen.
REGISTRATION
Print registration makes sure the black printing plane is properly aligned on the page. This is one of the steps in aligning
a new printhead. It is also the first step in aligning the duplex registration. See
“Quick Test” on page 195.
To set Registration:
1 Select Registration from the Diag Menu, and press Select.
2 Use Left or Right to select Print Quick Test, and press Select.
See
“Quick Test” on page 195 for addition information.
The message Printing... appears on the display, and the page prints.
Retain this page to determine the changes you need to make to the margin settings.
3 Press Select to enter the Registration.
4 Use Left or Right to select the margin setting you need to change, and press Select.
5 Use Left to decrease or Right to increase the offset values, and press Select to confirm the value. The message
Submitting changes displays, and the original margin setting screen appears.
The print registration ranges are:
Description Value Direction of change
Top margin -50 to +50
Each increment corresponds to 8 scans at a 600
dpi scan rate (0.0133 inches or 0.339 mm).
The default is 0.
A positive change moves the image down the
page and increases the top margin. A negative
change moves the image up and decreases the
top margin. No compression or expansion occurs.
7527
Service menus
193

Lexmark CX310 Specifications

General

Print Technology	Laser
Scan Technology	CIS
Scan Resolution	Up to 600 x 600 dpi
Duplex Printing	Manual
Display	2.4-inch color LCD
Processor Speed	800 MHz
Standard Memory	256 MB
Fax Speed	33.6 Kbps
Operating System Compatibility	Windows, Mac OS, Linux
Print Resolution	Up to 600 x 600 dpi
Connectivity	USB, Ethernet
Standard Paper Input	250 sheets
Scanner Type	Flatbed, ADF
Fax Resolution	300 x 300 dpi
Paper Capacity	250 sheets
Network Connectivity	Ethernet
Copy Speed	Up to 22 cpm (black), Up to 18 cpm (color)
