Lexmark CX310 - Lower Right Frame Removal

20 Remove the screw (P) above the frame.
21 Swing the left lower frame away from the printer, and remove.
Lower right frame removal
1 Remove the waste toner bottle. See “Waste toner bottle removal” on page 271.
2 Remove the imaging unit. See “Imaging unit (IU) removal” on page 267.
7527
Repair information
298
