Lexmark CX310 - Flatbed Pivot Link Removal

Flatbed pivot link removal
1 Remove the AIO link. See “AIO link removal” on page 319.
2 Remove the right scanner cover. See “Right scanner cover removal” on page 331.
3 Remove the AIO release lever. See “AIO release lever removal” on page 320.
4 Remove the screws (A) securing the flatbed link to the flatbed.
7527
Repair information
338
