Lexmark CX310 Service Manual

Assembly 1: Covers
Asm-index P/N Units/mach Units/FRU Description Removal procedure
1 40X7811 1 1 Output bin tray
“Output bin tray and exit bail removal” on
page 316
2 40X7810 1 1 Back AIO cable cover N/A
3 40X7845 1 1 Rear cover (CX310)
“Rear cover removal” on page 307
3 40X7846 1 1 Rear cover (CX410)
“Rear cover removal” on page 307
3 40X7814 1 1 Rear cover (CX510,
XC2132)
“Rear cover removal” on page 307
4 40X7809 1 1 Top cover assembly
(includes fan)
“Top cover assembly removal” on page 312
5 40X8674 1 1 Bracket, front toner door
pivot
N/A
6 40X7824 1 1 AIO link
“AIO link removal” on page 319
7 40X7802 1 1 Toner AIO cover
“AIO toner cover removal” on page 318
8 40X7823 1 1 Right AIO cover
“Right cover assembly removal” on page 256
9 40X7645 1 1 250‑sheet tray assembly
“Paper pick motor drive assembly (standard
tray) removal” on page 305
10 40X7801 1 1 Front cover
“Front cover assembly removal” on page 273
11 40X5490 1 1 Front middle cover
“Front middle cover removal” on page 275
12 40X5168 2 2 Pick tires
“Pick tire removal” on page 343
13 40X7632 1 1 Left cover
“Left cover assembly removal” on page 246
14 40X7579 1 1 System fan
“System fan removal” on page 311
NS 40X8089 1 1 650‑sheet drawer
“650‑sheet duo drawer assembly removal” on
page 341
NS 40X8091 1 1 650‑sheet tray assembly
“650‑sheet duo drawer tray assembly
removal” on page 340
NS 40X7812 1 1 Media bail
“Output bin tray and exit bail removal” on
page 316
