Assembly 2: Scanner
Asm-index P/N Units/mach Units/FRU Description Removal procedure
1 40X9054 1 1 ADF input tray
“ADF input tray removal” on page 328
2 40X5872 1 1 Bin full flag
“Bin‑full flag removal” on page 321
3 40X7833 1 1 Redrive assembly
“Redrive unit removal” on page 324
4 40X7829 1 1 Flatbed scanner assembly
“Flatbed scanner assembly removal” on
page 333
5 40X7827 1 1 AIO release lever with spring
“AIO release lever removal” on page 320
6 40X7819 1 1 Right scanner cover
“Right scanner cover removal” on
page 331
7 N/A 1 1 Operator panel cable N/A.
8 40X5480 1 1 USB thumbdrive cable
(CX510, XC2132)
“USB port connector removal” on
page 284
8 40X7836 1 1 USB thumbdrive cable
(CX410)
“USB port connector removal” on
page 284
9 40X7822 1 1 Flatbed pivot link (front left)
“Flatbed pivot link removal” on page 338
9 40X7834 1 1 Flatbed pivot link (rear right)
“Flatbed pivot link removal” on page 338
10 40X7820 1 1 Left scanner cover
“Left cover assembly removal” on
page 246
11 40X7842 1 1 Simplex top cover assembly
“Top cover assembly removal” on
page 312
11 40X7843 1 1 Duplex ADF top cover
assembly
N/A
12 40X6247 1 1 Simplex separator pad
assembly
“ADF separator pad removal” on page
329
12 40X9108 1 1 Duplex separator roller
assembly
“ADF separator pad removal” on page
329
13 40X7830 1 1 Duplex ADF assembly
“ADF assembly removal” on page 326
13 40X7831 1 1 Simplex ADF assembly
“ADF assembly removal” on page 326
NS 40X9110 1 1 Restraint pad N/A
NS 40X6243 1 1 Flatbed cushion N/A
NS 40X2252 1 4 Redrive spacer screws N/A
7527
Parts catalog
364
