Lexmark CX310 Service Manual

Assembly 3: Paperpath
Asm-index P/N Units/mach Units/FRU Description Removal procedure
1 40X7627 1 1 Printhead
“Printhead removal” on
page 324
2 40X7629 1 1 Fuser drive motor assembly
“Fuser drive motor assembly
removal” on page 257
3 40X7646 1 1 Lower left frame and lower right frame
with cable cover
“Lower left frame removal” on
page 292, “Lower right frame
removal” on page 298
4 40X7648 1 2X Miscellaneous screws
• Taptite M3 L6 panhead screw (10)
• M3x6 panhead screw (3)
• Shoulder screw (1)
• M3.5 internal lock washer (3)
• M3x8 screw (3)
• 3.5x6mm flat top screw (5)
• 3.5x8 flat top screw (5)
• Taptite M3 L4.5 panhead screw (3)
• M3x8LG W‑HD machine screw (3)
• Metal ROLN M3.5 8L screw (2)
• Plastic ROLN 2.9 8L screw (6)
• Plastic ROLN 3.5 6L screw (10)
• Plastic ROLN 3.5 8L screw (4)
• Plastic ROLN 3.5 10L screw (2)
• M3.5x8 SEMS machine screw (3)
N/A
4 40X7832 1 1 Screw packet
• M3.5 Internal Lock Washer
• M3 x 6 Shoulder Screw
• Sems Pl ROLN 2.9 x 8.2
N/A
4 40X7652 1 1 Miscellaneous springs
• Front cover latch (2x)
• ITU holddown (2x)
• Fuser holddown (2x)
• Primary tray bias (2x)
N/A
5 40X7610 1 1 Transfer module
“Transfer module removal” on
page 290
6 40X7614 1 1 Paper pick motor drive assembly
“Paper pick motor drive
assembly (standard tray)
removal” on page 305
7 40X7628 1 1 Main gear drive assembly with motors
“EP drive assembly removal”
on page 247
7527
Parts catalog
366
