Lexmark CX310 Service Manual

Assembly 4: Operator panels
Asm-index P/N Units/mach Units/FRU Description Removal procedure
1 40X7835 1 1 UICC to controller board
cable (CX310, CX410)
N/A
1 40X7837 1 1 UICC to controller board
cable (CX510, XC2132)
N/A
2 40X7836 1 1 USB cable (CX410)
“Operator panel removal (for CX310 and CX410
models only)” on page 276
2 40X5480 1 1 USB cable (CX510,
XC2132)
“Operator panel removal (for CX510 models
only)” on page 283
3 40X7818 1 1 Bezel (CX510)
“Operator panel bezel removal” on page 275
3 40X8709 1 1 Bezel (XC2132)
“Operator panel bezel removal” on page 275
4 40X7807 1 1 Operator panel assembly
(CX310)
“Operator panel removal (for CX310 and CX410
models only)” on page 276
4 40X7800 1 1 Operator panel assembly
(CX410)
“Operator panel removal (for CX310 and CX410
models only)” on page 276
4 40X7815 1 1 Operator panel assembly
(CX510)
“Operator panel removal (for CX510 models
only)” on page 283
5 40X9130 1 1 PCBA MFP UICC (CX510,
XC2132)
“Operator panel removal (for CX510 models
only)” on page 283
6 40X9115 1 1 Interface card (CX510,
XC2132)
“Operator panel removal (for CX510 models
only)” on page 283
7 40X7828 1 1 Cable (interface card to
UICC)
“Operator panel removal (for CX310 and CX410
models only)” on page 276, “Operator panel
removal (for CX510 models only)” on page
283
8 40X7861 1 1 Display (CX510, XC2132)
“Operator panel removal (for CX510 models
only)” on page 283
9 40X7838 1 1 Upper front cover
(CX510, XC2132)
“Operator panel removal (for CX510 models
only)” on page 283
9 40X7839 1 1 Upper front cover
(CX310, CX410)
“Operator panel removal (for CX310 and CX410
models only)” on page 276
10 40X7808 1 1 Front logo cover (CX310,
CX410)
“Operator panel logo plate removal” on
page 276
10 40X7816 1 1 Front logo cover (CX510,
XC2132)
“Operator panel logo plate removal” on
page 276
11 40X7840 1 1 User interface support
bracket (CX310, CX410)
“Operator panel removal (for CX310 and CX410
models only)” on page 276
11 40X7841 1 1 User interface support
bracket (CX510, XC2132)
“Operator panel removal (for CX510 models
only)” on page 283
12 40X9114 1 1 PCBA (CX410)
“Operator panel removal (for CX310 and CX410
models only)” on page 276
7527
Parts catalog
370

Lexmark CX310 Specifications

General

Print Technology	Laser
Scan Technology	CIS
Scan Resolution	Up to 600 x 600 dpi
Duplex Printing	Manual
Display	2.4-inch color LCD
Processor Speed	800 MHz
Standard Memory	256 MB
Fax Speed	33.6 Kbps
Operating System Compatibility	Windows, Mac OS, Linux
Print Resolution	Up to 600 x 600 dpi
Connectivity	USB, Ethernet
Standard Paper Input	250 sheets
Scanner Type	Flatbed, ADF
Fax Resolution	300 x 300 dpi
Paper Capacity	250 sheets
Network Connectivity	Ethernet
Copy Speed	Up to 22 cpm (black), Up to 18 cpm (color)
