• This equipment must be grounded for safe and proper operation.
• Do not supply power to a faulty inverter. If you find that the inverter is faulty, disconnect the
power supply and have the inverter professionally repaired.
• The inverter becomes hot during operation. Avoid touching the inverter until it has cooled to
avoid burns.
• Do not allow foreign objects, such as screws, metal chips, debris, water, or oil to get inside
the inverter. Allowing foreign objects inside the inverter may cause the inverter to
malfunction or result in a fire.
• Do not operate the inverter with wet hands. Doing so may result in electric shock.
• Do not modify the interior workings of the inverter. Doing so will void the warranty.
• The inverter is designed for 3-phase motor operation. Do not use the inverter to operate a
single phase motor.
• Do not place heavy objects on top of electric cables. Doing so may damage the cable and
result in an electric shock.
Maximum allowed prospective short-circuit current at the input power connection is defined
in IEC 60439-1 as 100 kA. LSLV-H100 is suitable for use in a circuit capable of delivering
not more than 100kA RMS at the drive‘s maximum rated voltage, depending on the
selected MCCB. RMS symmetrical amperes for recommended MCCB are the following
table.
Remarque
Le courant maximum de court-circuit présumé autorisé au connecteur d‘alimentation
électrique est défini dans la norme IEC 60439-1 comme égal à 100 kA. Selon le MCCB
sélectionné, la série LSLV-H100 peut être utilisée sur des circuits pouvant fournir un courant
RMS symétrique de 100 kA maximum en ampères à la tension nominale maximale du
variateur. Le tableau suivant indique le MCCB recommandé selon le courant RMS
symétrique en ampères.
