MacDon FlexDraper FD140 - Page 382

214683 358 Revision A
1024057
A
B
C
D
Figure 4.109: Driveline
12. Detach safety chain (C) from support bracket (B).
13. Pull collar (D) back to release driveline (A) from support
bracket. Remove the driveline from the support bracket.
1001516
A
Figure 4.110: Driveline and Output Shaft
14. Attach the driveline (A) to the combine output shaft.
HEADER ATTACHMENT/DETACHMENT
