Figure 5.8: Every 100 Hours
1020660
G
D
E
B
A
C
F
A - Knife Drive Box (Check Oil Level [B] on Dipstick [C]: Between Lowest Edge of Hole [D] and Bottom [E] of Dipstick)
F - Upper Cross Auger Bearing (One Place)
G - Main Drive Gearbox Oil Level. Refer to Lubricating Header Drive Gearbox, page 404
