Crane operation
11.4 Operation of the rated capacity limiter
11 - 56 3 302 819 en Operating manual
GMK3060
13.12.2018
Telescoping cylinder position display
The bar (2) shows the telescoping length of the telescoping cylinder – the total
bar length corresponds to 100%.
Telescoping direction display
The display is only active when telescoping with teleautomation and shows the
direction in which you must move the control lever for each respective telescoping
direction.
Current wind speed display
Shows the current wind speed in metres per second (m/sec) or miles per hour
(mph). The display flashes in colour in the vicinity of the maximum permissible
value (v
max
).
1 Start with Retract
2 Start with Extend
à Telescoping with semi-automation, p. 11 - 116
Yellow: about 90 - 100% of v
max
reached
Red: v
max
exceeded
