3. System Components
Figure 8: PATHWAY System Front View
3.1 Main Power and Coolant Temperature Control panel
Figure 9: Main Power and Coolant Temperature Control panel
The system power and coolant temperature control panel contains the following controls:
 Coolant temperature control panel – electronic thermostat for external cooling unit.
For additional instructions, refer to accompanying documentation.
 Main Power switch – PATHWAY system main power switch.
Mouse Tray
Thermode
Holders
Storage
Drawer
Main Power
and Cooling
Monitor
PATHWAY
Control Unit
Internal
Components:
Cooling Unit
and Isolation
Transformer
Coolant
Temperature
Control Panel
Main Power
Switch
