Pathway Technical Reference Manual
Proprietary 46 of 190
Figure 14: Trolley Electrical Connectors
5. Connect the PATHWAY power cord to an AC grounded outlet.
The SIP/SOPs (signal input and outputs) must be connected to medical
grade safety approved equipment for Canada and the United States by a
recognized certification agency, which is connected to the common
protective earth of the system.
Do not connect any equipment to a PATHWAY system that has not been
specifically authorized and approved by Medoc.
4.7 Software Installation
The installation procedure of MEDOC Main Station software can only be performed by a user
with windows system administrator rights. Without appropriate access rights, the
installation procedure may fail.
Users with previously installed versions of Medoc Main Station should review the upgrade
instructions before proceeding.
Depending on the current configuration of the computer, the MEDOC Main
Station installer may require the installation of additional components. The
installation procedure may take several minutes.
Disable any antivirus that runs on the PC before installing Medoc Main
Station.
Software installation can be performed only by Windows System
Administrators only
Users with Administrative privileges may not be enough.
The following instructions will guide you through the installation procedure:
1. Insert the USB drive into an available USB port on the computer
2. Open the folder to view files.
