Table 9: Status line parameters
Information
Description
Device
The device currently in use and connected to Medoc Main Station
Status
The current status of the system, either Demo or On-Line.
Com
Communication status between the system and the laptop. A green
indicator is displayed for ON and a red indicator for OFF.
State
The state of the Temperature Control Unit. The following modes are
available: Rest, Engineering, Safe and Test run.
Thermode
Indicates the type and model of the Thermode currently active: CHEPS
or ATS; 30x30mm; 16x16mm; 5x5mm; Intra oral; GSA; fMRI or
standard.
Heater
Temperature of the heater (CHEPS only).
TEC
Temperature of the Thermode (ATS only)
Water
Temperature of the coolant.
Safety
Safety status. A green indicator is displayed for OK and a red indicator
for Safe Mode activation– in Safe Mode Thermode power is disconnected
system remains non-functional, until the malfunction is resolved.
