Pathway Technical Reference Manual
Proprietary 39 of 190
3.2 Trolley Back Panel
Figure 10: System Back Panel
The back panel offers of the following access:
Communication and service ports door
o Communication port
o JTAG port
o Service Cable port for 4-bit TTL and analog output
o ECU control
Electrical Box Panel and Fuses Maintenance access door
Power Inlet and Outlet
Coolant reservoir access door
Do not connect any equipment to the service connectors during test
subject examination.
Communication and Service
Ports Door
Electrical box Panel and
Fuses Maintenance Access
Door
Cooling Unit Maintenance
Door
