15. Appendix D – fMRI Conditional PATHWAY
PATHWAY fMRI Thermode and accessories are defined and marked as MR
Conditional equipment according to the ASTM F2503–08.
PATHWAY Cart and MR filters are defined and marked as MR Unsafe
equipment according to the ASTM F2503–08.
WARNING:
Make sure that the Thermode is unblemished in order to prevent potential
harm to the test subject.
The fMRI PATHWAY system was tested in the following MR environments:
Field Strength: 3T; Max. Spatial gradient: 72 mT/m
Max. dB/dt: 346 T/m/s; RF Fields: max. power 35KW pep;
TX bandwidth: 800kHz; RX bandwidth: 500Hz-1MHz; maximal RF field
strength: 24,7 µT CP
SAR: whole body 4 W/kg, head 3.2 W/Kg
The fMRI PATHWAY system was tested in the following MR Sequences:
1. Fast Spin Echo (FSE) T1
2. Fast Spin Echo (FSE) T2
3. Spoiled Gradient Echo (SPGR)
4. Echo Planer Imaging (EPI) bold (fMRI)
5. Gradient Echo
15.1 PATHWAY system configuration in fMRI mode:
The fMRI PATHWAY system includes the following components:
 PATHWAY Trolley
 fMRI Emergency button extended cable
 fMRI COVAS (optional)
 fMRI Response Unit (optional)
 fMRI CHEPS filter and / or fMRI ATS filter
 fMRI CHEPS Thermode and / or fMRI ATS Thermode
