2 Overview
The PolarFire
®
FPGA family includes multiple embedded low-power, performance-optimized
transceivers. Each transceiver has both the physical medium attachment (PMA), protocol physical
coding sub-layer (PCS) logic, and interfaces to the FPGA fabric. The transceiver has a multi-lane
architecture with each lane natively supporting serial data transmission rates from 500Mbps (250 Mbps
with interpolation) to 12.7 Gbps.
The transceiver includes all required analog functions for high-speed data transmission between devices
over printed circuit boards (PCB) and high-quality cables. The transceiver is suitable for a variety of
device-to-device communication protocols, as shown in the following table.
Table 1 • Supported Serial Protocols
Protocol Standard/Version Protocol Standard/Version
PCIe Gen1 CPRI
1
1. Common Public Radio Interface (CPRI) Specification V7.0 (2015-10-09).
CPRI-1, 2, 3, 4, 5, 6, 7, 7A, 8, 9
PCIe Gen2 SATA
2
2. SATA is supported using PMA only mode.
1.0a
XAUI IEEE 802.3 SATA
2
2.0
Interlaken
3
3. Interlaken Protocol Specification, v1.2.
10.3125 SATA
2
3.0
Interlaken
3
6.375 SDI-SD SMPTE 259M
10GBASE-R IEEE 802.3 SDI-HD SMPTE 292M
10GBASE-KR
4
4. PMA supports 10GBASE-KR operation.
IEEE 802.3 SDI-3G SMPTE 424M
Fibre Channel 1GFC SGMII
Fibre Channel 2GFC 1000BASE-X IEEE 802.3
Fibre Channel 4GFC LiteFast Proprietary Lightweight Serial
Protocol Interface (up to 12.7
Gbps, 8b10b mode only.)
Fibre Channel 8GFC RXAUI N/A
JESD204B LV-OIF-SxI5 QSGMII
JESD204B LV-OIF-6G-SR SLVS-EC
JESD204B LV-OIF-11G-SR DisplayPort
USXGMII CoaXPress
