Functional Description
Microsemi Proprietary and Confidential UG0677 User Guide Revision 9.0 32
3.3.2.2 64b6xb System Registers
There are specific registers used for configuring the 64b6xb lane function options in the PolarFire Device
Register Map. Other fields are required to properly program the clocks, resets, XCVR, and lane overlay
blocks and data path steering. Required system register field setting combinations required for enabling
64b6xb lane usage.
Table 10 • System Registers Affecting 64b6xb Data Path
Register
Page xls
Register
Name Field Name Description
pcslane L64_R0 L64_CFG_BYPASS_GEARBOX When = 1, both transmit and receive gearbox
functions are bypassed.
L64_CFG_BYPASS_SCRAMBLER When = 1, both the scrambler and the descrambler
are bypassed.
L64_CFG_BYPASS_DISPARITY Enable the Interlaken block disparity generation
and checking blocks by setting
cfg_bypass_disparity=0.
L64_CFG_BYPASS_8B_MOD When = 0 to obtain 64-bit fabric interfaces. Set
cfg_bypass_8B_mode=1 for 32-bit fabric
interfaces.
L64_CFG_GRBX_64B67B When = 1 for 67-bit blocks (Interlaken).
L64_CFG_GRBX_SM_C49 When = 1 to enable IEEE 802.3 Clause 49 receiver
lock state machine. Value of
L64_CFG_GRBX_SM_C82 must be set as inverse
of this bit.
L64_CFG_GRBX_SM_C82.
When = 1 to enable IEEE 802.2 Clause 82 receiver
lock state machine behavior (40G link version).
Value of L64_CFG_GRBX_SM_C49 must be set
as inverse of this bit.
L64_CFG_BER_MON_EN. When = 1 to enable the BER Monitor in the
receiver. The BER Monitor is useful in CPRI
applications.
L64_CFG_BER_1US_TIMER_VAL This register should be set to the number of clock
beats which most closely represents one
microsecond. This field is used by the BER Monitor
to time the 125 microsecond interval. Examples:
CPRI rate 7A setting is 0x18B; CPRI rate 8 setting
is 0x140; CPRI rate 9 setting is 0x107.
