Implementation
Microsemi Proprietary and Confidential UG0677 User Guide Revision 9.0 81
4 Implementation
PolarFire transceiver blocks support many high-speed serial protocols. These protocols are supported
using multiple transceiver building blocks that the user constructs using the transceiver configurators in
the Libero design software. The Libero configurator allows the user to set the reference clock and data
rates for particular protocols. This information is then used to properly generate the configuration settings
for the PMA, and the associated interface logic. The configurators build components that are used to
instantiate/configure the transceiver-specific hardware macros including the PMA and PCS blocks using
the Libero SmartDesign software.
4.1 Libero Configurators
Three explicit PolarFire configurators are the preferred tool for wrapper generation needed to instantiate
transceiver primitive macros called PF_XCVR_REF_CLK, PF_TX_PLL, and PF_XCVR. The configurator
is part of the Libero SoC design tools and is available when the PolarFire macros are downloaded from
the Libero catalog.
The following table provides details on three Libero transceiver configurators in the Libero Software:
transmit PLL, transceiver reference clock, and transceiver interface modules. The transmit PLL
(PF_TX_PLL) and transceiver interface (PF_XCVR) modules are used when the transceivers are
implemented in the Libero FPGA design. The transceiver reference clock (PF_XCVR_REF_CLK) is used
when the dedicated input clock from the top-level pins are used. Optionally, this is not used if the
transceiver reference clock comes from the PLL or from the FPGA fabric. The user must instantiate and
configure these 3 blocks in their transceiver design.
As the FPGA designer makes selections in the each transceiver module configurators, it automatically
guides and narrows down the subsequent choices and defaults. Each configurator maintains a module
diagram while the designer selects the module properties. Once all the choices are made, the
configurator generates an RTL netlist that instantiates the required macros specific to the requirements
of the design. Only the relevant ports appear in the generated macro. This section describes how to enter
these configuration parameters in the transceiver configurator GUIs.
Table 25 • Transceiver Configurator Component List
Configurator Macro Details
Transmit PLL PF_TX_PLL Generates the TxPLL/TxPLL_SSC based on the provided input to
the GUI. The PF_TX_PLL generates the BIT_CLK for the
transceiver.
Transceiver
Reference Clock
PF_XCVR_REF_CLK Generates the reference clock based on the provided input to the
GUI—selection of differential or single-end input buffer and selection
of single or dual clock inputs to the transmit PLL clock interface.
Transceiver Interface PF_XCVR_ERM Configures the requested number of lanes (4 lane maximum) with
the same PMA and PCS settings—the lanes required by the design
and CDRPLL settings.
