5.3.2.1 PDC Supported Attributes and Values
The following table list the PDC supported attributes and values. For more information about he
description of the attributes, see Transmitter, page 109.
Table 37 • TX Attributes and Values
Name Direction Values Default
TX_EMPHASIS_AMPLITUDE Output 400mV_with_-3.5dB 400mV_with_-1.0dB
100mV_with_0dB
200mV_with_0dB
200mV_with_-1.0dB
200mV_with_-2.5dB
200mV_with_-3.5dB
200mV_with_-4.4dB
200mV_with_-6.0dB
300mV_with_0dB
400mV_with_0dB
400mV_with_-1.0dB
400mV_with_-2.5dB
400mV_with_-4.4dB
400mV_with_-6.0dB
500mV_with_0dB
600mV_with_-3.5dB
600mV_with_-6.0dB
800mV_with_0dB
800mV_with_-1.0dB
800mV_with_-2.5dB
800mV_with_-3.5dB
800mV_with_-4.4dB
800mV_with_-6.0dB
1000mV_with_0dB
1000mV_with_-1.0dB
1000mV_with_-2.5dB
1000mV_with_-3.5dB
1000mV_with_-4.4dB
1000mV_with_-6.0dB
TX_IMPEDANCE Output 150 100
100
85
