Extraction Tools for Hydraulic and Pneumatic Actuators -
continued
Table 10-1 Extraction and Installation Tool Overview - Actuators
Actuator Series Extraction Tool
Main Assembly
Piston / Cylinder Body /
Liner Extraction Tool
Packages
[Master Series Resource
Guide Page Number]
Piston / Piston Seal
Installation Packages
[Master Series Resource
Guide Page Number]
PN2300x/PN2300xL
PN2300xAR/PN2300xLAR
EXTOOLAS10 EXTOOL2300P1
[MS11.04.020]
PS0001TOOL01
[MS11.04.050]
HY5500x
HY550Xx/HY550XxL
EXTOOLAS10 EXTOOL5500P1
[MS11.04.010]
N/A
HY6500x/HY6500xAR
HY650Xx/HY650XxAR
HY650XxL/HY650XxLAR
HY6600x/HY6600xAR
HY6700x/HY6700xAR
HY7100x/HY7100xAR
HY710X x/HY710XxAR
HY710XxL/HY710XxLAR
HY8700x
VPAC0008/VPAC0009
VPAC0010/VPAC0011
EXTOOLAS10 EXTOOL6500P1
[MS11.04.015]
PS0003TOOLx
[MS11.04.050]
HY680SA/HY680SAL EXTOOLAS10 EXTOOL680SAP
[MS11.04.035]
PS0004TOOLx
[MS11.04.050]
HY681SA/HY681SAL EXTOOL681SAP
[MS11.04.035]
HY8400x
HY8500x
HY8600xAR
HY8800x
EXTOOLAS10 EXTOOL8400P1
[MS11.04.030]
PS0011TOOLx
[MS11.04.050]
PN6400x/PN6400xAR
PN6410x/PN6410xAR
EXTOOLAS10 EXTOOL6400P
[MS11.04.025]
N/A
PN6400SA EXTOOLAS10 EXTOOL6400SAP
[MS11.04.040]
N/A
