Mold-Masters Hot Runner - Sevg Plus in Plate Mounted Systems; SE40-20 Model; SE20-15 Model

12.5 SeVG Plus in Plate Mounted Systems
12.6 SE40-20 Model
1. SeVG Plus
actuator
2. Frame plate
3. Actuator plate
4. Manifold plate
2
3
4
1
Note: non cooled
model shown
Figure 12-4 SE40-20 actuator in a Hot Runner system
12.6.1 SE20-15 Model
1
2
3
4
1. SeVG Plus actuator
2. Frame plate
3. Actuator plate
4. Manifold plate
Figure 12-5 SE20-15 actuator in a Hot Runner system
12-5SEVG PLUS ACTUATOR
Hot Runner User Manual
