Section 13 - E-Drive
WARNING
Ensure that you have fully read “Section 3 - Safety” before assembling,
integrating or operating the E-Drive system.
13.1 Typical E-Drive System
Figure 13-1 E-Drive system
2
3
4
5
7
8
6
1
1. Insulation plate
2. Locating ring
3. Gear box
4. Servo motor
5. Gear mount
6. Interface plate
7. Top plate
8. Fixed idler
9
10
12
13
14
11
9. Drive pulley
10. Idler pulley
11. Timing belt
12. Ball-screw pulley
13. Tensioning idler pulley
14. Tensioning idler screw
