15.14 Torque Settings
CAUTION
Gate seals are to be torqued at ambient (room) temperature and then re-
torqued at processing temperature to the torque value specied. This is to
prevent material leakage from the gate seal.
CAUTION
NOTE
Torque values in the tables should be referenced against the torque values
on the General Assembly drawing for a specic system.
15.14.1 Torque Settings of Dura-Plus Gate Seals
Table 15-4 Torque Settings of Dura-Plus Gate Seals
Product Line Product Size Torque [ft-lb] Torque [N·m]
Dura Plus Deci 25-28 34-38
Hecto 35-40 47-54
Mega 42-48 57-65
15.14.2 Torque Settings of Master-Series Gate Seals
Table 15-5 Torque Settings of Master-Series Gate Seals
Product Line Product Size Torque [ft-lb] Torque [N·m]
Master Series Femto Lite 6-7 8-9
Femto 6-7 8-9
Pico 12-13 16-18
Centi 20-22 27-30
Deci 25-28 34-38
Hecto 35-40 47-54
Master-Series
Melt Disk
Centi 10-11 14-15
15.14.3 Torque Settings of Summit-Series Gate Seals
Table 15-6 Torque Settings of Summit-Series Gate Seals
Product Line Product Size Torque [ft-lb] Torque [N·m]
Summit Series Femto 6-7 8-9
Pico 12-13 16-18
Centi 20-22 27-30
