19.3 Melt-CUBE Design A

Figure 19-4 Melt-CUBE design A components

(Not supplied by

Mold-Masters)

Cavity insert

1. M4 screw (SHCSM4X20)

2. M6 screw (SHCSM6X25)

3. Load wedge

4. Melt wedge

5. Melt-CUBE anti rotation dowel

6. Melt-CUBE manifold

7. Gate seal assembly

8. Cavity insert

9. Wedge dowel pin

10. Retainer clamp

19-4

MELT-CUBE SYSTEMS

Hot Runner User Manual
