5.10.4 Nozzle Insertion—MasterSHIELD Centi, Deci, and

Pico

Refer to the following gure to identify the components.

Figure 5-8 Master-Series Pico nozzle with optional MasterSHIELD components

1. Hardened washer

2. Disc spring

3. Nozzle retainer

4. Nozzle

1. Clean the seating bore of the nozzle well.

2. Install the bottom hardened washer.

5-16

ASSEMBLY

Hot Runner User Manual
