5.10.5 Nozzle Insertion—MasterSHIELD Femto

Figure 5-9 Master-Series Femto nozzle with optional MasterSHIELD components

1. Hardened washers

2. Disc springs

3. Nozzle retainer

4. Nozzle

1. Clean the seating bore of the nozzle well.

2. Install the bottom hardened washer.

3. Apply high temperature grease to the rst spring.

5-19ASSEMBLY
