Figure 19-8 Critical cutout dimensions
19.4.4 Melt-CUBE Design B: Cleaning
CAUTION
Ensure that the critical surfaces are not damaged during the cleaning
process.
CAUTION
1. Clean any plastic residue from hot runner interface surfaces. See Figure
19-9.
Clean plastic from surfaces shown
here.
Figure 19-9 Remove plastic residue from surfaces
2. Clean the manifold interfaces with a ne grade (400 or 600 grit) polishing
stone. See Figure 19-10.
Figure 19-10 Clean manifold interfaces
3. Wipe down the melt block critical surface and the Melt-CUBE manifold
interfaces with lacquer thinner.
19-21MELT-CUBE SYSTEMS
