19.1 Identify Your Melt-CUBE Design
IMPORTANT
Melt-CUBE design A and Melt-CUBE design B are not interchangeable.
19.1.1 The Melt-CUBE Design A
The Melt-CUBE design A uses ve screws. See Figure 19-1.
Note multiple screws
Figure 19-1 Melt-CUBE design A
19.1.2 The Melt-CUBE Design B
The new Melt-CUBE design B uses a single screw. See Figure 19-2.
Note single screw
Figure 19-2 Melt-CUBE design B
