Section 19 - Melt-CUBE

Systems

WARNING

Ensure that you have fully read “Section 3 - Safety” before integrating,

operating or doing maintenance procedures on the Melt-CUBE

system.

CAUTION

Please correctly identify the type of Melt-CUBE in your system before

assembling, installing or doing maintenance on your Melt-CUBE. The

assembly and installation instructions are di󰀨erent for each design. Failure

to obey the correct instructions will damage the parts. Ensure that the

correct instructions are followed for your design of Melt-CUBE.

CAUTION

Mold-Masters has di󰀨erent Melt-CUBE designs. See “19.1 Identify Your Melt-

CUBE Design” for more information. If in doubt, contact your

Mold-Masters representative for assistance.

For the Melt-CUBE design A, see “19.3 Melt-CUBE Design A”.

For the Melt-CUBE design B, see “19.4 Melt-CUBE Design B”.

19-1MELT-CUBE SYSTEMS
