13.2 Assembly
WARNING
Review “Section 3 - Safety” on page 3-1 before performing any assembly
procedures.
The Mold-Masters E-Drive system is shipped pre-assembled and requires
minimal pre-installation assembly. The following details the assembly /
installation procedures for various components of the E-Drive.
1. Top plate
2. Fixed bearing (angular contact ball bearing)
3. Ball-screw
2
1
3
Figure 13-4 Complete assembly (center section)
