Section 11 - Slimstack
Actuator
11.1 Introduction
WARNING
Ensure that you have fully read “Section 3 - Safety” before assembling or
installing the Slimstack actuator.
This section provides the information for the assembly and installation of a
Slimstack actuator.
Refer to the General Assembly drawings for part names, sizes and quantities
for any components.
See “Figure 11-1 Slimstack actuator assembly” on page 11-2 for a full view of
the assembly.
