18.6 Optional Quick Disconnect Terminal Ends
Optional quick disconnect terminal end kits are available on request. The kit
consists of:
• QDISC-CRIMP Tool
• TERMCON09 (Power)
• TERMCON10 (Thermocouple)
Figure 18-3 Power quick disconnect terminal ends
Figure 18-4 Thermocouple quick disconnect terminal ends
Locator
Locator
Slide
Back of
Tool
Anvil
Jaws
Crimper
Jaws
Ratchet
Disengaged
Wire Stop
Wire Size
Markings
Wire Stop
Slot (In Contact)
1. Crimper jaws
2. Locator
3. Locator slide
4. Back of tool
5. Anvil jaws
6. Ratchet disengaged
7. Wire stop slot
(in contact)
8. Wire stop
9. Wire size markings
1
2
3
4
5
6
7
8
9
Figure 18-5 QDISC - CRIMP tool
